The D3 Pocket Panel

PORTABLE TOUCHSCREEN EFIS WITH SYNTHETIC VISION

Meet the D3 - the newest edition of Dynon’s popular Pocket Panel. Now featuring Synthetic Vision, the D3 Dynon Pocket Panel lets pilots supplement their often unreliable legacy instrumentation with an affordable, portable electronic attitude indicator. Both of the included cockpit mounting options require no tools, allowing the D3 to be deployed in any aircraft without regulatory approval.

Dynon Pocket Panels are true artificial horizon instruments based on the same technology that drives Dynon's Electronic Flight Instrument Systems (EFIS).

INCLUDES ALL MOUNTS AND ACCESSORIES:

The D3 comes with two portable mounting options, no tools required. Because it does not require modification to the aircraft's design, no regulatory approval is required to use a D3 Pocket Panel in any aircraft. The first mount included is a RAM® suction cup mount. The second is a 3-1/8" portable "pinch" mount that allows the D3 to be easily mounted in an empty existing instrument panel hole without any fasteners.

  • AC Wall Charger
  • DC Vehicle Charger
  • Charging Cable
  • Mounting Cradles (two included)
  • RAM® Portable Suction Cup Mount
  • Portable “Pinch” Mount for Standard 3-1/8” Instrument Hole
  • External GPS Antenna (not required in many cockpits)



A Little Attitude for Everyone
Now with Synthetic Vision

D3 Pocket Panel Product Tour

The D3 features the same reliable, proven AHRS engine from Dynon’s best-selling panel-mounted products for experimental, light sport, and type certificated aircraft.


Preview image
  • More

    GPS Ground Speed

    Close
  • More

    Menu and Touchscreen

    The D3 is controlled through a touchscreen interface. Touch the menu icon in the upper left corner of the screen to access most controls and settings. Swipe left and right on the main scr een to choose between various displays.

    Close
  • More

    True EFIS Attitude in a Portable Package

    The D3 uses the Dynon's proven MEMS-based attitude sensors. Accurate pitch and roll: A true artificial horizon.

    Close
  • More

    GPS Altitude and Vertical Speed

    Close
  • More

    Rechargeable Li-Ion Battery

    At least >5.5 Hours of use on a single charge

    Close
  • More

    Ambient Light Sensor

    Auto-dimming screen for comfortable night flight

    Close
  • More

    GPS Ground Track

    Close

D3 Pocket Panel Features

The D3 features the same reliable, proven AHRS engine from Dynon’s best-selling panel-mounted products for experimental, light sport, and type certificated aircraft.


New and Improved Display

D3 New and Improved Display with Touchscreen Interface

  • Synthetic Vision
  • Intuitive Touchscreen Interface
  • Improved Brightness for Superior Sunlight Readability

G-Meter

D3 G-Meter

  • Second page displays current load factor
  • Records minimum and maximum Gs since last pilot reset

Portable Mounting Options

D3 RAM suction mount and 3-1/8 panel hole pinch mount

  • No installation costs!
  • Versatile portable mounts: RAM suction mount and 3-1/8" panel hole "pinch" mount both included
  • Internal Li-Ion battery for hours of portable use DC and AC power adaptors included
  • Truly pocket sized, approx. 3.5" x 3.25" x 1"

True Attitude plus GPS Flight Data

D3 Pocket Panel GPS Data

  • GPS ground speed and track (heading)
  • GPS altitude and vertical speed
  • Turn rate
  • Slip/skid ball
  • Dimmable screen for night flight
